To verify that the USB Interface drivers are installed properly, check to
ensure the Data Logger Software can recognize a device.
When the interface cable is connected to the PC the blue LED power
indicator light should be on. If the indicator light is not on, unplug
the interface cable, wait 5 seconds and plug it back into the PC.
Start the MadgeTech Data Logger Software. (If necessary, see the
software manual for additional information on the software)
Your device(s) will appear in the list displayed, select your device in
this list and choose your desired start method.
Additional Information
For additional information or troubleshooting assistance,
visit us online at www.madgtech.com, contact us for support
at e-mail [email protected] or call (603) 456-2011.
Remove the Warning Label to expose the USB connector. Connect
one end of the USB cable to the USB port of the IFC406.
Connect the other end to a USB port on your PC. When the IFC406 is
plugged in, a New Hardware Found message will appear in the lower
right corner of your screen. The new drivers will automatically configure
themselves for use with the Interface cable. A message will then appear that the
new hardware is installed and ready to use.
The installation of the USB data
logger interface is complete!
Connecting the Data Logger
Interface
Test the Data Logger Interface
Operation
2
3
A
A
B
C
D
B
Found New Hardware
USB Device
Warning: Install driver before connecting this device.
To install the drivers for the IFC406, click on the Drivers and Third
Party Tools link on the MadgeTech Installer Options window panel. In
the next window click on Install USB Interface Drivers. A window will
appear prompting for a directory and to start the installation.
The default directory is C:\Program Files\MTI-USB\Datalogger Interface. If you
choose to change the location of the install directory, select the Change Install
Location button. Once you have the install location set select the Install button
to start the installation.
C
