Therm•A•Lert Series
Identify a location for the RFC1000 base station.
3 Plug the RFC1000 into the USB port on the base station computer.
AC Powered
Install the MadgeTech software, USB Drivers located on the website. 1
Please ensure the MadgeTech software is running.
2
Note: The RFC1000 can transmit to other transceivers up to 4000’ outdoors and 1000’
indoors. RFC1000-Repeaters act as repeaters and may be plugged into wall outlets to
transmit data over greater distances.
Quick Start Guide
4000’ outdoors or 1000’ indoors
“On” Switch
4 Plug additional RFC1000 repeaters into wall outlets.
5 Flip the black switch on the back of the Therm•A•Lert to the on
position (0 is off, 1 is on).
6 A Therm•A•Lert icon will automatically appear in the software, showing
the device is recognized.
Note: The red LED will illuminate to signify the RFC1000 has been connected correctly.
Determine the distance from the remote RFC1000’s to the base module. If the distance is
greater than 1000 feet indoors, or 4000 feet outdoors, or there are walls/obstacles/corners
that need to be maneuvered around, setup additional RFC1000-Repeaters as needed.
Note: If the wireless device is not on the network, it will only appear if the “only show
claimed wireless devices” is unchecked. The checkbox acts as a filter so you have the option
of seeing the devices that are connected to your computers RFC1000.
