© American Audio ® - www.americandj.com - Commander Plus™ Instruction Manual Page 4
NOTE: This product satisfies FCC
regulations when shielded cables
and connectors are used to con-
nect the unit to other equipment.
To prevent electromagnetic inter-
ference with electrical appliances
such as radios and televisions, use
shielded cables and connectors for
connections.
WARNING: TO PREVENT FIRE OR ELECTRIC
SHOCK HAZARD, DO NOT EXPOSE THIS
UNIT TO RAIN, LIQUIDS, OR MOISTURE
CAUTION: TO PREVENT ELECTRIC SHOCK
DO NOT USE THIS (POLARIZED) PLUG
WITH AN EXTENSION CORD, RECEPTACLE,
OR OTHER TYPE OF ELECTRICAL OUTLET
UNLESS THE WIDE BLADES CAN BE
CAREFULLY INSERTED INTO A MATCHING
WIDE SLOT.
ATTENTION: POUR PREVENIR LES CHOCS
ELECTRIQUES NE PAS UTILISER CETTE
FICHE POLARISEE AVEC UN PROLON-
GATEUR, UNE PRISE DE COURANT OU
UNE AUTRE SORTIE DE COURANT, SAUF SI
LES LAMES PEUVENT ETRE INSEREES A
FOND SANS EN LAISSER AUCUNE PARTIE
A DECOUVERT.
COMMANDER PLUS™ ELECTRICAL SAFETY PRECAUTIONS
VOLTAGE SELECTOR SWITCH
LINE VOLTAGE SELECTION
• The desired voltage may be set with the
VOLTAGE SELECTOR switch on the rear
panel (using a flat head screw driver).
• Do not force the VOLTAGE SELECTOR
switch as this may cause damage
• If the VOLTAGE SELECTOR switch does
not move smoothly, please contact a quali-
fied service technician.
The serial and model number for this unit is
located on the rear panel. Please write down
the numbers here and retain for future refer-
ence.
Model No._____________________________
Serial No._____________________________
Purchase Notes:
Date of Purchase_______________________
Dealer Name__________________________
Dealer Address_________________________
_____________________________________
_____________________________________
Dealer Phone__________________________
90,11,12
REAR PANEL
PLUSRP
DIRK ELECTRONIC CORPORATION
SHU P,F YUEN
1/1
