- Working Currency : 350mA (max)
- Working Voltage : DC +5V : +5.50V ~ +4.50V
: DC+12V : +15V ~ 9V
- Working Temperature : 0 – 70 ℃
- Ring Spec. : Fq=15Hz ~ 71Hz, V=35Vrms (above)
- Tone Spec. : HGF=-4, LGF=-6, ±2db
: HGF=-9, LGF=-11, ±2db(CTR21)
- Pulse Spec. : M.B.R=39 ±2 , P.P.S=10 ±0.5
- PCB Size : 96mm X 90mm
EMC & PTT Support: FCC Part15 & Part68/CE/CTR21(Option)
1.2 Unpacking the Modem
The complete modem package should include:
1) The modem unit.
2) This user manual.
3) An RJ-11 to RJ-11 phone cable.
4) Data and fax communications software (Optional).
5) Windows 95/98 Driver
Carefully inspect the package for shipping damage. If damage is
found, repack the modem in the original packing material and
contact your dealer.
1.3 A Look at the Modem Card
Phone: Accepts a Telephone set Connected Parallel to your
Modem.
Line: Accepts the RJ-11 Cable that links your Modem to a
Telephone line or to a 2-Wire Leased-Line.
PC/104: The PC/104 connectors give you the flexibility to attach
PC/104 modules.
