Register Range Units Default

Function

S25

0-255 s or 0.01s 5

Delay to DTR Off

S26 0-255

0.01s 1

RTS-to-CTS

Delay

S27

-

-

73(49h)

General Bit Mapped Options Status

S28

-

-

0

General Bit Mapped Options Status

S29

0-255 10ms

70

Flash Dial Modifier Time

S30

0-255 10s

0

Disconnect Inactivity Timer

S31

-

-

194(C2h)

General Bit Mapped Options Status

S32 0-255

ASCII 17(11h) XON

Character

S33 0-255

ASCII 19(13h) XOFF

Character

S34-S35 - -

-

Reserved

S36

-

-

7

LAPM Failure Control

S37 - -

0

Line

Connection

Speed

S38

0-255 s

20

Delay Before Forced Hang-up

S39

-

-

3

Flow Control Bit Mapped Options
Status

S40

-

-

168(a8h)

General Bit Mapped Options Status

S41

-

-

195(C3h)

General Bit Mapped Options Status

S42-S45 - -

-

Reserved

S46 - -

138

Data

Compression

Control

S48

-

-

7

V.42 Negotiation Control

S82 - -

128(40h)

LAPM

Break

Control

S86

0-255 -

-

Call Failure Reason Code

S91 0-15

dBm 10(country

dependent)

PSTN Transmit Attenuation Level

S92 0-15

dBm 10(country

dependent)

Fax Transmit Attenuation Level

S95

-

-

0

Result Code Messages Control

♦=Register value may be stored in one of two user profiles with the &W command.
