Pc-series power supply, How to order, Contact your supplier pc12 – Seametrics PC-SERIES User Manual
Page 4: Specifications* dimensions
LT-65650282-011413
1/14/13
Seametrics Incorporated • 19026 72nd Avenue South • Kent, Washington 98032 • USA
(P) 253.872.0284 • (F) 253.872.0285 • 1.800.975.8153 • www.seametrics.com
MODEL
Single 24 Vdc, unregulated, outlet =
PC3
Dual 12/24 Vdc, regulated, wall or panel mount =
PC42
Single 12 Vdc, regulated, wall or DIN rail =
PC12
HOW TO ORDER
PC-SERIES
Power Supply
CONTACT YOUR SUPPLIER
PC12
Input Power
Output Voltage/Current
Output Noise
Screw Teminal Wire
MTBF
Operating Temperature
Regulatory Approvals
Environmental
SPECIFICATIONS*
DIMENSIONS
*Specifications subject to change • Please consult our website for
current data (www.seametrics.com).
.71
3.54
2.4
85-264 Vac, 45-65 Hz
12 Vdc +/-1%, /1A (Regulated)
<10 mV p-p
12 - 24 AWG
500,000 hours
-13˚ to 158˚ F (-25˚ to 70˚ C)
UL, UL/C (Canada) listed, CE
IP20, non-condensing
3.8
4.0
2 x 0.16 diameter
Extendable Mounting Tabs
