If the meter pulses once every gallon, set the

accumulator for the number of gallons desired

between timer cycles. For meters with multiple pulses

per gallon, multiply the desired number of gallons

by the pulses per gallon. For meters with multiple

gallons between pulses, divide the desired gallons by the

gallons per pulse.

Example:

The goal is one timer output every 60 gallons.

The meter has a 5 gallons per pulse (G/P) output.

60 gallons

5 gallons/pulse

How To Determine TIMER (Power On Time) Setting(s).

The TIMER time is set to release the desired amount

of chemical to be fed or water to be bled, and is

specific to the pump, valve, etc. being used. When deter-

mining the power on time, check that it isn’t more than

the expected time between cycles, to avoid feeding and

bleeding out of order or possible overlap conditions, by

calculating:

If this result is greater than the determined power on

time, enter the determined power on time into the TIMER

setting.

INSTALLATION and OPERATION

INSTALLATION

Setting.

Using the thumb screws, remove the front cover.

Test for TImer Output.

To test the timed output(s), press the

“TEST 1” or “TEST 2” button. The red output indicator should

light and remain on for the pre-set number of seconds.

How To Determine Accumulator Setting(s):

OPERATION

Press the SET button.

The green ACC (accumulator) light

at the upper left corner of the display will begin blinking,

indicating that the accumulator is ready to be set.

Turn the knob

clockwise to increase or counter-

clockwise to decrease until the desired number of

pulses is reached.

Press SET again.

The red TIMER indicator will light.

Set the desired time in seconds

for output power to

turn on.

Repeat the process

to set Accumulator 2 and Timer 2

as needed.

Press SET again

to display "SEq" (sequential).

Turn the knob

in either direction to switch from "SEq" to

"nSEq" (non-sequential). Sequential operation prevents

the Timer 2 output from operating while Timer 1 is on,

so that chemical feed does not occur during bleed.

Non-sequential operation allows either timer to operate

immediately when its count is reached.

Press SET again

to return to normal operation.

1)

2)

3)

4)

5)

6)

7)

8)

= 12 pulses (accumulator setting)

After setting (when the unit has returned to normal operation,

indicated by no blinking indicators), any display can be selected

at any time by turning the knob. Turning the knob clockwise

causes clockwise rotation among the indicator lights. Stop

turning the knob after arriving at the desired display. This is the

display that will remain until another display is selected.

Possible Overlap Conditions.

If the power on time is longer

than the time between on cycles, the on time won’t elapse

before the next on cycle is supposed to start. If this happens,

the power output will remain on, and “OUF” (Overlap, Under

wait time, Failure) will appear on the screen, to alert the user

that a problem has occured. This situation can be avoided by

following the equation above in “How To Determine TIMER

(Power On Time) Setting(s)”. Also note that if in sequential

mode, the sum of the on time, must be less than the minimum

seconds between cycles. Otherwise, one relay will hold up the

other and an overlap condition will occur.

Accumulator Function.

The accumulator adds received

pulses once every second, and when the accumulator number

is reached or exceded, the power will turn on. However, any

pulses above the accumulator number will not roll over to the

next cycle, so if the accumulator is set to 20, with 19 pulses

already having been received, and 2 more are received in the

next second, the accumulator will read 0 once the power is

turned on, and not 1.

Cycle Size (Gallons)

60 sec

minimum seconds

Max. Flow Rate (GPM)

Min.

between cycles

X

=
