Rola-Chem Pro Series Pump PN 522105 2013/11/26 Page: 6 of 8
7. PARTS LIST
ITEM PART No. DESCRIPTION MODEL
RC252 RC25/53 RC103 RC503
1 527253 ENCLOSURE COVER NS X X X X
2 527251 ENCLOSURE BODY NS X X X X
3 525253 SCREW 10-24 x 4-1/2 PPH STL ZP X X X X
4 521752 HOUSING, BODY X X X
5 521751 HOUSING, COVER X X X
6 523408 KNOB, LOCK ASSY X X X
7 523400 ROLLER, TRI NS-ASSY (3 ROLLER) X X X
8 525233 SCREW 10-24 x 3/4 PTH SST X X X
9 521225 HOUSING, PUMP X
10 525004 BRASS STUD 10-32 X
11 525140 WING NUT 10-32 X
12 523332 ROLLER, 2 INCH H-BLOCK X
13 521058 GEAR MOTOR, 1R, 120V 120 V
521094 GEAR MOTOR, 1R, 240V 240 V
521805 GEAR MOTOR, 4R, 120V 120V
521806 GEAR MOTOR, 4R, 240V 240V
521316 GEAR MOTOR, 16R, 120V 120V
521317 GEAR MOTOR, 16R, 240V 240V
524756 GEAR MOTOR, 30R, 120V 120V
524755 GEAR MOTOR, 30R, 240V 240V
14 524752 FAN, 2.5 INCH X X X X
15 524717 TIMER/POT ASSY 120 V ALL 120 V PUMPS
524718 TIMER/POT ASSY 240 V ALL 240 V PUMPS
16 521154 KNOB, TIMER X X X X
17 524711 SWITCH ASSY, 3 WAY X X X X
18 523252 HOSE ASSY-TYGON/VINYL 8 INCH NOTE A X
523118 HOSE ASSY-TYGON/VINYL 13.5 INCH NOTE A X X X
523414 HOSE ASSY-NORPRENE/VINYL 8 INCH NOTE A X
523140 HOSE ASSY-NORPRENE/VINYL 13.5 INCH NOTE A X X X
19 523250 TYGON HOSE ASSY-8 INCH NOTE B X
523115 TYGON HOSE ASSY-13.5 INCH NOTE B X X X
523251 NORPRENE HOSE ASSY-8 INCH NOTE B X
523114 NORPRENE HOSE ASSY-13.5 INCH NOTE B X X X
20 523102 LUBRICANT, E-Z GLIDE, 3GRAM X X X X
21 525114 CLAMP, HOSE #8 X X X X
22 520111 FITTING, HOSE CONNECTOR, 3/8 BARB X X X X
23 520110 CLAMP, HOSE #6 X X X X
24 520120 TUBING, VINYL .31 X .44 X 66 INCH X X X X
25 523110 WEIGHT, HOSE 7/16 X X X X
26 520112 RETAINER-HOSE WEIGHT X X X X
27 527158 BRASS INJECTION FITTING X X X X
28 525113 SEAL, INJECTION FITTING (SPARE) X X X X
29 520113 ADAPTER, PP1/4MNPTx 3/8 BARB X X X X
30 521170 CHECK VALVE, PVC, 3/8 BARB X 1/4 NPT X X X X
31 521160 CHECK VALVE, PVC, 3/8 X 3/8 BARB X X X X
32 524155 POWER CORD, 18-3SJT, 120V PUMP-CORDED,120 V
524156 POWER CORD, 18-3SJT, 240V PUMP-CORDED,240 V
33 524070 STRAIN RELIEF CORDED PUMPS
34 524115 J-BOX
35 524135 LOCK NUT, STEEL 1/2 CONDUIT MODELS
36 524110 NIPPLE, 1/2 X 1
37 525214 GROUND SCREW #8, GREEN X X X X
38 525255 LOCK WASHER (GROUND SCREW) X X X X
NOTE A : COMPLETE HOSE ASSEMBLY
ITEM #18 INCLUDES: HOSE ASSY (ITEM #19) AND ITEMS 23 THRU 27
NOTE B HOSE, CLAMP AND FITTING
ITEM #19 INCLUDES TYGON HOSE (OR NORPRENE HOSE), CLAMP (ITEM 21) AND FITTING (ITEM #22)
