Revo REHB0309-1 Quick Installation Guide User Manual
Page 2
REHB0309-1, Quick Installation Guide
• Connection Cable
NO
Wire Color
Description
1
Red: DC12V
White: GND
Main Power, 2pin terminal, DC12V 700mA(8.4W)
2
Black
Ethernet,
RJ-45 port compatible with 10/100Mbps having PoE
functionality.
Modular Jack
Parts and Description
Carefully remove the contents from the box, and verity that nothing was damaged
during shipment.
2
