18
At this time, the F2E protocol could not be changed.
To add the other camera:
1. Select the blank line (- - -) by moving the joystick down or up.
2. Twist the handle of the joystick clockwise, then the next camera number displays or press camera
number and CAM key, if that number is not already defined, the camera number displays.
3. Set the appropriate protocol and port moving the cursor ( m)by the joystick.
Alarm check option is ON: P-D (PELCO-D), P-P (PELCO-P)
Alarm check option is OFF: F2, F2E, P-D (PELCO-D), P-P (PELCO-P)
4. Set the appropriate baud rate of the camera.
5. Repeat step 1-4 to add a new camera.
6. Press CTRL to save and exit.
7. To change the camera, repeat step 2-6 after selecting the desired camera number.
Press OFF to delete the saved camera.
Press the ESC key to exit without saving.
Note) The baud rate of the F2E is according to the value of the set baud rate menu.
When the keyboard has that the alarm check option is OFF, the camera setup displays the blank value after
the first power on. At this time, set all cameras according to the procedure above.
3.4 Time / Date
Set the KBD controllers¶ Time & Date
3.5 ALARM
1. Alarm Check
When set to ON, the KBD controller will check alarm signal and each port
can be connected 32 dome cameras. When set to OFF, it will not check
alarm signal and each port can be connected 128 dome cameras.
2. Alarm Beep
When set to ON, the KBD controller will sound beep when alarm signal is
detected.
Save and exit
Save the changed settings and return to the previous menu
NOTE: When domes are installed more than 64 at one dome port, you should set the alarm
TIME/DATE
1.Dispaly :ON
2.Year :2007
3.Month :JUL
4.Day :02 MON
5.Hour :12
6.Minute :20
Save and Exit
Alarm
1.Check :ON
2.Beep :ON
Save and Exit
