9
1) FACTORY Returns to the level which was set by the manufacturer for
shipment.
RESET
EXIT
1) EXIT Saves all the setting menus and then exits.
1) SHARPNESS Can be adjusted SHARPNESS of outlines.(0~31)
2) BLUE Adjust B-GAIN value.(0~100)
3) RED Adjust R-GAIN value.(0~100)
ADJUST
4) PRIVACY
AREA SELECT Select MASK area number.
AREA DISPLAY Select MASK ON/OFF
LEFT/RIGHT Adjust the location of the MASK area with boundary LEFT
and RIGHT
WIDTH Adjust width of MASK area
TOP/BOTTOM Adjust the location of the MASK area with boundary
TOP and BOTTOM.
HEIGHT Adjust height of MASK area
COLOR Select MASK color. (0~15)
5) SYNC Select Internal or Line Lock mode.
INT This mode is necessary for using the internal synchronization.
L/L This mode is necessary for the operation of multi camera because
it synchronizes the camera phase by using the external signal
(AC Signal).
PHASE Sync phase is adjustable in line lock mode.
6) LANGUAGE You can change the OSD language using the LEFT/RIGHT
Setup switch.
1. LENS DC
2. EXPOSURE
3. WHITE BAL AWB
4. DAY NIGHT AUTO
5. 3DNR ON
6. SPECIAL
7. ADJUST
8. RESET
9. EXIT
►
SPECIAL
1.CAM TITLE ON
2.D-EFFECT
3.MOTION OFF
4.PRIVACY ON
5. SYNC INT
6.LANGUAGE ENGLISH
7.RETURN RET
►
PRIVACY
AREA SELECT AREA1
AREA DISPLAY ON
LEFT/RIGHT
IIIIIIIIIIIIIIIIII
8
WIDTH
IIIIIIIIIIIIIIIIII
20
TOP/BOTTOM
IIIIIIIIIIIIIIIIII
10
HEIGHT
IIIIIIIIIIIIIIIIII
35
COLOR
IIIIIIIIIIIIIIIIII
0
RETURN RET
►
