BASE INSTALLATION
Fasten Camera Fix screw(1X) and align the dome camera
with it like above picture.
Fasten Camera Fix Screws (2X) and align the bullet camera
with it like above picture.
1
Finally, lock dome window with locking screw(M3X20mm)
in a accessory kit.
2
4
M3X20mm Tapping Screws
Camera Fix Screw
M3X20mm Tapping Screws
Camera Fix Screw
Maximum recommended load is 1.5kg.(Bullet Camera)
