NSi Industries 451A - Manual

OPERATING INSTRUCTIONS
FOR TECHNICAL SUPPORT
[email protected]
888.500.4598
451A
DESCRIPTION:
TIME SET:
SETTING TABS:
EXAMPLE:
24hr dial with 48 captive tabs
30 minute settings per tab
Turn dial so current time lines
up with pointer (FIG. 1)
To turn “ON”, slide tap in the down position
To turn “OFF”, slide the tab in the up position (FIG. 2)
Set timer to turn “ON” load at 6:00pm and turn
load “OFF” at 5:00pm: Slide all the tabs in the
down position between 6:00pm and 5:00am and
place all tabs in the up position between 5:00am and 6:00pm.
(FIG. 1)
(FIG. 2)
A DIVISION OF NSi INDUSTRIES, LLC
USA • 800.321.5847 • www.nsiindustries.com
