EL-USB-1
Temperature Data Logger with USB Interface
DIMENSIONS
All dimensions in mm (inches)
98.0 (3.86)
26.0
(1.02)
Internal Temperature Sensor Location
WARNING: Handle lithium batteries carefully, observe warnings on battery casing.
Dispose of in accordance with local regulations.
BATTERY REPLACEMENT
We recommend that you replace the battery every 12 months, or prior to logging critical data.
The EL-USB-1 does not lose its stored readings when the battery is flat or when the battery is replaced; the data
logging process will however be stopped and cannot be re-started until the battery has been replaced and the
logged data has been downloaded to PC.
Only use Sonnenschein 3.6V 1/2AA lithium batteries (SL-750/S). Check with your supplier that the battery you
are ordering is 'press fit' and is not fitted with solder tags. Before replacing the battery, remove the EL-USB-1 from
the PC.
Note:
Leaving the EL-USB-1 plugged into the USB port for longer than necessary will cause some of the battery capacity to be lost.
Specifications liable to change without prior warning EL-USB-1 Issue 2 April/2004 M.C. Applies to EL-USB-1/2
