FEATURES
DATA LOGGER SET-UPS ORDERING INFORMATION
Stock Number
EL-USB-LITE
1-off Data Logger, Battery,
Software on CD
Replacement Batteries (5 pack) BATT-3VX5
LASCAR ELECTRONICS LTD.
MODULE HOUSE
WHITEPARISH
WILTSHIRE
SP5 2SJ
UK
TEL: +44 (1794) 884567
FAX: +44 (1794) 884616
E-mail: [email protected]
LASCAR ELECTRONICS (HK) LIMITED
FLAT C, 5/FL., LUCKY FTY. BLDG.
63-65 HUNG TO ROAD
KWUN TONG
KOWLOON
HONG KONG
TEL: +852 2797 3219
FAX: +852 2343 6187
E-mail: [email protected]
www.lascarelectronics.com
LASCAR ELECTRONICS INC.
3750 West 26th Street
Erie
PA 16506
USA
TEL: +1 (814) 835 0621
FAX: +1 (814) 838 8141
• -10°C to +50°C (+14 to +122°F) Measurement Range
E-mail: [email protected]
 30 Minute Sample Rate
 1 Month Battery Life
 Red/Green Alarm Status Indication via Button
 USB Interface for Set-up and Data Download
2 User-programmable Alarm Thresholds
 Dimensions : 68 x 18 x 9.4mm (2.7" x 0.7" x 0.4")
EL-USB-LITE
Low Cost USB Temperature Data Logger
Specifications liable to change without prior warning
This low cost data logger measures and stores up to 4,080 temperature readings over a -10 to +50°C (+14 to +122°F)
EL-USB-LITE Issue 1 March/2006 M.C.
measurement range with a fixed 30 minute sample rate and a battery life of 1 month continuous use. Press the button
and a red/green LED indicates whether a preset alarm level has been breached.
The data logger is configured and the stored data downloaded by plugging the module into a PC's USB port and running
the purpose designed control software under Windows 98, 2000 or XP. The downloaded data can be graphed, printed
and exported to other applications. The latest version of the control software may be downloaded free of charge from:
. A battery is already fitted. To start logging , pull out the tab. www.lascarelectronics.com
 Logger Name
 °C, °F
 High and Low Alarm Levels
Start Time and Start Date
SPECIFICATIONS
Specification Min. Typ. Max. Unit
Measurement range -10 (+14) +50 (+122) °C (°F)
Internal resolution 1 (2) °C (°F)
Accuracy (overall error) 2.5 ( ) °C (°F) +
Operating temperature range -10 (+14) +50 (+122) °C (°F)
Logging rate every 30 minutes
Battery Life (CR1620 Lithium coin cell) 1 Month
+4.5
Easy to install and use, the control software runs under
Windows 98, 2000 and XP (Home and Professional
Editions)*. It allows the user to set up and download any
EL-USB-Lite.
WINDOWS CONTROL SOFTWARE
