15mm (0.6“) Digit Height
Programmable Decimal Points
Auto-zero
Auto-polarity
200mV d.c. Full Scale Reading (F.S.R.)
Single Rail Version
DPM 2000
3
½ Digit LCD Module
The DPM 2000 uses advanced components and construction techniques to provide an unrivalled combination of high performance,
elegant appearance and low cost. The module uses a bandgap reference for extra temperature stability. For single rail operation, the
DPM 2000S features a built-in negative rail generator, enabling the meter to measure a signal referenced to its own power supply 0V.
Specification
Min.
Typ.
Max.
Unit
Accuracy (overall error) *
0.05
0.1
% (±1 count)
Linearity
±1
count
Sample rate
3
samples/sec
Operating temperature range
0
50
°C
Temperature s
30
ppm/°C
Supply
DPM 2000
7.5
9
14
(V+ to V-)
DPM 2000S
3.5
5
6.5
V
Supply current
DPM 2000
150
DPM 2000S
500
A
Input leakage current (Vin = 0V)
1
10
pA
* To ensure maximum accuracy, re-calibrate periodically.
tability
voltage
µ
Stock Number
Standard Meter
DPM 2000
Single Rail Version
DPM 2000S
ON BOARD
SOLDER LINKS
SCALING RESISTORS
SCALING
NOTE
67.5 (2.66)
32.5
(1.28)
27.5
(1.08)
19.0
(0.75)
29.5
(1.16)
29.5
(1.16)
60.0 (2.36)
53.0 (2.09)
62.5 (2.46)
Ø2.50
(0.10)
c d e
f
g
TEST XB3
XDP -5V CLK XG3 V+ RBG REF
-
REF+
E3 BP AB POL REF
HI
REF
LO
COM L
H V-
I
I
+ -
pH
% V g °F °C A
m
M K
DP1 DP2 DP3
~
: -
µ
Ω
Display in TEST mode
a. 1.00 (0.04)
b. 9.00 (0.35)
c. 1.25 (0.05)
d. 5.50 (0.22)
e. 4.00 (0.16)
f. 0.50 (0.02)
g. 2.54 (0.10)
LMP
8
13
12
H5
9
6
14
11 4 2 7
5
1
3
10
Rb
Ra
Two resistors Ra and Rb may be fitted in order to alter
the full scale reading (F.S.R) of the meter - see table.
The meter will need re-calibration.
Ensure that link 10 is open if fitting Ra.
