Dimensions and weights
Dimensions
a b c d e f
approx. Weight
mm inches mm inches mm inches mm inches mm inches mm inches kg lbs
97 3.82 25 0.99 75 2.95 max. 65 max.2.56 94 3.70 23 0.91 0.1 0.22
Panel recess
Flow table
Float material
stainless steel 1.4571 (316 Ti), glass
Calibration data: Water at 20°C (68°F)
Air at 20°C, (68°F), 1.2 bar abs. (17.4 psig) (in normal state)
100% flow values
Rangeability 10 : 1
Air Water Ball Ø
DK 701 (Scale on frontplate) DK 702 Scale on glass cone) DK 702 (Scale on glass cone)
mm inches l/h SCFH l/h SCFH l/h US GPM
4
4
4
4
4
4 0.16
0.16
0.16
0.16
0.16
0.16 -
-
-
-
-
40 -
-
-
-
-
1.5 5
8
16
25
40
60 0.2
0.3
0.6
1
1.5
2.5 -
-
-
-
-
2.5 -
-
-
-
-
0.01
6
6
6
6 0.24
0.24
0.24
0.24 100
150
250
- 4
6
10 100
250
500
800 4
10
20
30 5
12
25
40 0.02
0.05
0.1
0.16
Product liability and warranty
Responsibility for the suitability and usage to the intended purpose of these flowmeters rests solely with the operator. Improper installation or
improper operation of the flowmeters may lead to the loss of warranty. In addition, the "General conditions of sale" which forms the basis of the
purchase contract are applicable.
If you need to return the unit for checkout or repair, please pay strict attention to the following points:
Due to statutory regulations concerning protection of the environment and the health and safety of our personnel, KROHNE may only handle, test
and repair returned flowmeters that have been in contact with liquids if it is possible to do so without risk to personnel and environment.
This means that KROHNE can only service your unit if it is accompanied by a certificate confirming that the flowmeter is safe to handle.
If the unit has been operated with toxic, caustic, flammable or water-endangering liquids, you are kindly requested:
● To check and ensure, if necessary by rinsing or neutralizing, that all the cavities are free from such dangerous substances.
● To enclose a certificate with the flowmeter confirming that is safe to handle and stating the liquid used.
KROHNE regret that we cannot service your device unless it is accompanied by such a certificate and thank you for your understanding.
