BM100 Remote Operation - HC 275 / AMS
Dev.-Rev. EE, DD-Rev. 03
© 2000 KROHNE Meßtechnik D-47058 Duisburg Page 10
Attachment B
(continued from the previous page)
Designations:
- not applicable if 'Interface Option' is disabled
(L) - Local AMS variable, that is not read/written to
instrument
* - Read-only variable
Process Variables
Status
-----------------------------------
Diagnostics and Test
Calibrate
-----------------------------------
Master reset
Reset user EEPROM
Reset factory EEPROM
-----------------------------------
Entry Code
Service Code
-----------------------------------
Audit Trail
Drawing Notes ...
Help ...
-----------------------------------
Clear Offline Configuration
Compare Configurations
Configuration Properties
Basic Setup
•
Location
----- Basic Functions -----
•
Tank Height
•
Hold Distance
•
Time Constant
•
Window Frozen
•
Level Window
•
Interface Window
------------- A01 ------------
•
Function I1
•
Scale I1 Max
•
Scale I1 Min
------------- A02 ------------
•
Function I2
•
Scale I2 Max
•
Scale I2 Min
Sensor
------------ Tank-------------
•
Tank Height
•
Hold Distance
----------- Limits -----------
•
Snsr Upper Lim
•
Snsr Lower Lim
•
Snsr Min Span
-------- Correction ---------
•
Window Frozen
•
Level Window
•
Interface Window
•
Detection Delay
•
Epsilon R
•
Settling
Process Input
•
Length Unit
•
Volume/Mass Unit
•
Time Constant
------ Display format ------
------ (AMS screens) -------
•
Level format (L)
•
Volume format (L)
Analog Outputs
------------- A01 ------------
•
Function I1
•
Range I1
•
Scale I1 Max
•
Scale I1 Min
•
AO Alarm type
------------- A02 ------------
•
Function I2
•
Range I2
•
Scale I2 Max
•
Scale I2 Min
•
AO Alarm type
HART
-- Device Identification --
•
Location
•
Device ID *
•
Date
•
Descriptor
•
Message
------ Protocol Data ------
•
Universal revision *
•
Num request preams *
•
Num response preams
•
Polling address
Service
---- Basis Parameters -----
•
Probe Length
•
Offset
•
Bottom Short-Cir.
•
Probe Position
•
Inter. Selection
------- Application ---------
•
Measurement Mode
------- Calibration ---------
•
Derivative Reference
•
Elec. Cal. Speed
•
Mech. Cal. Speed
•
Air Epsilon R
----------- Reset -------------
•
Serial Number
•
French Cmd Nmb
•
German Cmd Nmb
Device
•
Model *
•
Manufacturer *
•
Fld dev rev *
•
Software rev *
•
Write protect *
--------- User Data ---------
•
Serial Number *
•
French Cmd Nmb *
•
German Cmd Nmb *
•
Option
•
Probe Type
Strap Table, 1-20
•
Number of points
First 20 pairs
Level ! Volume/Mass
KROHNE BM100 45f9ee03
BM100 Menu Tree AMS
Strap Table, 21-40
Next 20 pairs
Level ! Volume/Mass
Strap Table, 41-50
Last 10 pairs
Level ! Volume/Mass
