DEVICE DESCRIPTION
2
9
H250 M9
www.krohne.com 03/2013 - 4002616501 AD H250 M9 NEPSI Ex nA R01 en
Maximum permitted product temperature in Maximum permitted product temperature in Maximum permitted product temperature in Maximum permitted product temperature in °C C C C
Maximum permitted product temperature in Maximum permitted product temperature in Maximum permitted product temperature in Maximum permitted product temperature in °F F F F
Maximum permitted product temperature T
m
Heating jacket TK T6 T5 T4 T3 T2, T1
none with HT
Version T
amb
≤ 40 ≤ 60 ≤ 60 ≤ 40 ≤ 60 ≤ 40 ≤ 60
ESK II / ESK2A and ESK3-PA
DN15,
DN25
DN15 85 100 135 200 183 200 183
x 85 100 135 200 200 300 300
DN50 DN25 85 100 135 200 165 200 165
x 85 100 135 200 200 300 300
DN80,
DN100
DN50,
DN80
85 100 135 200 150 200 150
x 85 100 135 200 200 300 252
K1 / K2
DN15,
DN25
DN15 85 100 135 200 200 200 200
x 85 100 135 200 200 300 300
DN50 DN25 85 100 135 200 200 200 200
x 85 100 135 200 200 300 300
DN80,
DN100
DN50,
DN80
85 100 135 200 200 200 200
x 85 100 135 200 200 300 300
Maximum permitted product temperature T
m
Heating jacket TK T6 T5 T4 T3 T2, T1
none with HT
Version T
amb
≤ 104 ≤ 140 ≤ 140 ≤ 104 ≤ 140 ≤ 104 ≤ 140
ESK II / ESK2A and ESK3-PA
DN15,
DN25
DN15 185 212 275 392 361 392 361
x 185 212 275 392 392 572 572
DN50 DN25 185 212 275 392 329 392 329
x 185 212 275 392 392 572 572
DN80,
DN100
DN50,
DN80
185 212 275 392 302 392 302
x 185 212 275 392 392 572 485
K1 / K2
DN15,
DN25
DN15 185 212 275 392 392 392 392
x 185 212 275 392 392 572 572
DN50 DN25 185 212 275 392 392 392 392
x 185 212 275 392 392 572 572
DN80,
DN100
DN50,
DN80
185 212 275 392 392 392 392
x 185 212 275 392 392 572 572
