DEVICE DESCRIPTION
2
9
H250 M40
www.krohne.com 03/2013 - 4002616601 AD H250 M40 NEPSI Ex nA R01 en
Maximum permitted product temperature in °C
Maximum permitted product temperature T
m
[°C]
Heating
jacket TK T6 T5 T4 T3 T2, T1
None with HT
version T
amb
[°C]
≤ 40 ≤ 60 ≤ 65 ≤ 60 ≤ 65 ≤ 40 ≤ 60 ≤ 65 ≤ 40 ≤ 60 ≤ 65
ESK4
DN15
DN25
DN50
DN15
DN25
85 100 90 135 135 200 160 140 235 160 140
x 85 100 100 135 135 200 200 200 300 300 270
DN80
DN100
DN50
DN80
85 100 85 135 130 200 150 130 220 150 130
x 85 100 100 135 135 200 200 200 300 300 255
ESK4-T
DN15
DN25
DN50
DN15
DN25
85 90 70 135 120 200 140 120 220 140 120
x 85 100 85 135 135 200 200 200 300 290 225
DN80
DN100
DN50
DN80
85 85 70 130 115 200 130 115 200 130 115
x 85 100 80 135 135 200 200 200 300 270 215
ESK4-FF / ESK4-PA
DN15
DN25
DN50
DN15
DN25
70 60 not
admissi
ble
135 125 200 150 125 235 150 125
x 85 60 135 135 200 200 200 300 300 240
DN80
DN100
DN50
DN80
65 60 135 120 200 140 120 220 140 120
x 85 60 135 135 200 200 200 300 300 225
K1/K2
DN15
DN25
DN50
DN15
DN25
85 100 100 135 135 200 200 180 290 205 180
x 85 100 100 135 135 200 200 200 300 300 300
DN80
DN100
DN50
DN80
85 100 100 135 135 200 185 170 260 185 170
x 85 100 100 135 135 200 200 200 300 300 300
