Supplementary Documentation BM 70 A, BM 70 P with PROFIBUS-PA
3. Menu settings for PROFIBUS-PA
(see Section 8.4 in the Installation and Operating Instructions)
The following settings need to be made for operation of the BM 70 A/P on a PROFIBUS-PA network. Note that the
service “set slave address” is not being supported. Therefore the address can only be set by way of the local display
and operator interface.
Function (Fct.) Input range Default value Description
3.3.5 BAUDRATE Select 31250 Bd. 31250 Bd. If Fct. 3.3.7 is set to ”PROFIBUS”, the baud rate is
fixed at 31250 Bd.
3.3.6 ADDRESS Input 0 ... 126 126 If Fct. 3.3.7 is set to ”PROFIBUS”, the default value
of the address is 126.
3.3.7 PROTOCOL Select HART
KROHNE/PC
PROFIBUS
PROFIBUS Selection of the communications protocol.
Set to PROFIBUS when delivered.
(only when appropriate hardware provided)
4. Technical data,
PROFIBUS Ident-No. F901
Hardware
Physical
to IEC 61158-2 and the FISCO model
Bus characteristics 9... 30 V; 0.3 A max. ; 4.2 W max.
Base current
10 mA
FDE yes: separate fault disconnection electronics
provided
Fault current 6 mA; (fault current = max. continuous
current – base current)
Starting current lower than base current
”Ex” approval EEx ia IIC T6 or EEx ib IIC/IIB T6 in
conformity with the FISCO model
Connection independent of polarity
Software
GSD
all KROHNE GSD files supplied on diskette
Device profile complete implementation of Profile B, V2.0
Functional blocks level [m], distance [m], in addition volume [m 3 ]
as cyclic value plus status
mentioned units are default units
Address range 0-126, default 126,
“set slave address” not supported
Operator control local display and operator interface at device
SAP`s
1; typically the number of service access points
is equal to the number of class 2 masters
(operating tools)
