9.2 Dimensions
OPTISOUND 3010 C
1 2
155mm (6
7
/ 64
")
22mm (
55
/ 64
")
66mm
(2
19
/ 32
")
ø 39mm
(1 17 /
32
")
ø 74mm
(2 58 /
64
")
60mm
(2 23 /
64
")
G1½A /
1½"NPT
Fig. 23: OPTISOUND 3010 C
1 Dead band: 0.25 m (0.8 ft)
2 Meas. range: in liquids up to 5 m (16.4 ft), in solids up to 2 m (6.6 ft)
