8 American Dryer Corp. 113403 - 14
SL31 Specifications _______________________________________________________________
!
Note
The manufacturer reserves the right to make changes in specifications at any time without notice or obligation.
Gas
Electric
Steam
Shaded areas are stated in metric equivalents 9/30/05
MAXIMUM CAPACITY (DRY WEIGHT) 30 lb 13.61 kg
TUMBLER DIAMETER 30” 76.20 cm
TUMBLER DEPTH 27” 68.58 cm
TUMBLER VOLUME 11.04 cu ft 312.62 L
TUMBLER/DRIVE MOTOR 1/4 hp 0.19 kW
BLOWER/FAN MOTOR 1/2 hp 0.37 kW
DOOR OPENING (DIAMETER) 19-3/8” 49.21 cm
DOOR SILL HEIGHT 14-7/8” 37.78 cm
WATER CONNECTION 3/4”-11.5 NH (No rth A me ri ca)
3/4” B.S .P.T. (Outside North A meri ca)
DRYERS PER 20’/40’ CONTAINER 12 / 28
DRYERS PER 48’/53’ TRUCK 34 / 38
VOLTAGE AVAILABLE 120-240V 1ø 2w 50/60 Hz
APPROXIMATE NET WEIGHT 285 lb 129.27 kg
APPROXIMATE SHIPPING WEIGHT 310 lb 140.61 kg
AIRFLOW 60 Hz 360 cfm 10.19 cmm
50 Hz 300 cfm 8.49 cmm
HEAT INPUT 55,000 B tu/hr 13,860 kcal/hr
EXHAUST CONNECTION (DIAMETER) 6” 15.24 cm
COMPRESSED AIR CONNECTION N / A
COMPRESSED AIR VOLUME N / A
INLET PIPE CONNECTION 1/2” M.N.P.T.
3/8” M.B .S .P.T. (C E and A ustrali a Only )
VOLTAGE AVAILABLE 200-416V 1,3ø 2,3,4w 50/60 Hz
APPROXIMATE NET WEIGHT 285 lb 129.27 kg
APPROXIMATE SHIPPING WEIGHT 310 lb 140.61 kg
AIRFLOW 60 Hz 360 cfm 10.19 cmm
50 Hz 300 cfm 8.49 cmm
EXHAUST CONNECTION (DIAMETER) 6” 15.24 cm
COMPRESSED AIR CONNECTION N / A
COMPRESSED AIR VOLUME N / A
OVEN SIZE
kW Btu/hr kcal/hr
7.9 26,962 6,794
8.3 28,327 7,138
9.0 30,716 7,740
11.3 38,566 9,719
12.4 42,320 10,665
12.5 42,661 10,751
13.5 46,074 11,611
VOLTAGE AVAILABLE 120-240V 1ø 2w 50/60 Hz
APPROXIMATE NET WEIGHT 305 lb 138.35 kg
APPROXIMATE SHIPPING WEIGHT 330 lb 149.69 kg
AIRFLOW 60 Hz 360 cfm 10.19 cmm
50 Hz 300 cfm 8.49 cmm
STEAM CONSUMPTION 63 lb/hr 28.58 kg/hr
OPERATING STEAM PRESSURE 150 psi max 10.34 bar
EXHAUST CONNECTION (DIAMETER) 6” 15.24 cm
COMPRESSED AIR CONNECTION N / A
COMPRESSED AIR VOLUME N / A
BOILER HORSEPOWER (NORMAL LOAD) 1.75 B hp
SUPPLY CONNECTION 1/2” F.N.P.T.
RETURN CONNECTION 1/2” M.N.P.T.
