1” Pin
2” Pin
Make sure you put the pins
in the side panel at the
same height as the pins
in the Divider Panel
1”
pin
Edge Banding Out
Slide Divider Panels Into Place
A. Slide each panel down using a set/pair of pins as illustrated on the top front brace. The magnet
block takes the place of one pin.
Install Shelf Support Pins
2” long into/through divider panels as illustrated. Make sure these pins align with shelf support pins in
side panels.
Note: Use the four extra 2” pins
if you want the middle shelf at a
different height than side shelves.
