Connecting the 08PIA-DK
1-4 08PIA-DK Digital Piano with ATSAM9708 and ATSAM3303 User Guide
6163A–DRMSD–12-Jul-05
1.4.7 Metronome Possible settings are:
! On
! Off
The metronome signature can be set. Follow the steps below:
1. Hold the “Metronome” button” pressed down.
2. Use the “Tempo +/-” buttons to choose the signature.
Available signatures are 1/4, 2/4, 3/4, 4/4, 6/4, 6/8, 12/8.
1.4.8 Sequencer Use “Rec Mode”, “Play/Rec Start”, “Track 1" and “Track 2" buttons.
Below is an example of how to use the sequencer:
! Record track 1:
1. Press the “Rec Mode” button. The “Rec Mode” LED is lit.
2. Press the “Track 1" button. “Play/Rec Start” and “Track 1" LEDs are flashing.
3. Start recording by playing the keyboard or by pressing the “Play/Rec Start” but-
ton. “Play/Rec Start” LED stops flashing and stays lit.
4. Stop recording by pressing the “Rec Mode” button. “Rec Mode” LED is off.
! Play track 1:
1. If “Track 1" LED is not lit, press the “Track 1" button. The “Track 1" LED is lit.
2. Press the “Play/Rec Start” button to play what is recorded on Track 1. The
“Play/Rec Start” LED is lit.
! Record track 2:
1. Press the “Rec Mode” button. “Rec Mode” and “Track 1" LEDs are lit.
2. Press the “Track 2" button. “Play/Rec Start” and “Track 2" LEDs are flashing
3. Start recording by playing the keyboard or by pressing the “Play/Rec Start” but-
ton. “Play/Rec Start” LED stops flashing and stays lit.
4. Stop recording by pressing the “Rec Mode” button. “Rec Mode” LED is off.
! Play track 1 and track 2:
1. If “Track 1" LED is not lit, press the “Track 1" button. The “Track 1" LED lights up.
2. If “Track 2" LED is not lit, press the “Track 2" button. The “Track 2" LED lights up.
3. Press the “Play/Rec Start” button to play what is recorded on Track 1 and Track
2. The “Play/Rec Start” LED is lit.
