Connecting the 08PIA-DK
08PIA-DK Digital Piano with ATSAM9708 and ATSAM3303 User Guide 1-3
6163A–DRMSD–12-Jul-05
1.4.2 Reverb Type Possible settings are:
! Room1
! Room2
! Hall
Reverb depth can be set for each instrument. Follow the steps below:
1. Hold the “Reverb” button pressed down.
2. Use the “Tempo +/-” buttons to adjust the reverb depth in the range from 0 to 20
1.4.3 Chorus Possible settings are:
! Off
! Chorus1
! Chorus2
Chorus depth can be set for each instrument. Follow the steps below:
1. Hold the “Chorus” button pressed down.
2. Use the “Tempo +/-” buttons to adjust the chorus depth in the range from 0 to 20.
1.4.4 Dynamic Curve Possible settings are:
! Normal
! Hard
! Soft
! Fixed Velocity (default = 64)
The value for the fixed velocity can be set:
1. Press the “Dynamic” button repeatedly until all the “Dynamic” LEDs are off.
2. Hold the “Dynamic” button pressed down.
3. Use the “Tempo +/-” buttons to adjust the fixed dynamic in the range from 0 to
127.
1.4.5 Sympathetic
Resonance Press the “Set” button repeatedly.
! 0 = No resonance
! 1 = Low resonance depth
! 2 = Medium resonance depth
! 3 = High resonance depth
1.4.6 Demo Press “Demo”, then press the “Instrument Select” button 1, 2 or 3.
