13. Disconnect charger from the power supply when not in use. This will reduce the risk of electric shock or
damage to the charger if metal items should fall into the opening. It will also help prevent damage to the charger
during a power surge.
14. Risk of electric shock. Do not touch the uninsulated portion of output connector or uninsulated battery terminal.
15. Save these instructions. Refer to them frequently and use them to instruct others who may use this tool. If you
lend this tool to someone else, also lend these instructions to them to prevent misuse of the product and possible
injury.
KNOW YOUR SCREWDRIVER
1-1/4" bit collet 2-Power indicator
3-Pivot release button 4-Direction of rotation selector
(Forward/Center Lock/Reverse)
5-Charger port 6-Trigger switch
7-LED worklight switch 8-LED worklight
9-Charger adapter 10-Charger jack
Screwdriver bit collet. To hold 1/4" bits, bit holder, and socket adaptor should be a separate line.
Power indicator. The screwdriver is equipped with a power indicator which is used to display the battery’s
remaining run time.
Stick/Pistol pivot release button. The screwdriver has been designed so that it can be operated as a stick
screwdriver or a pistol screwdriver.
Direction of rotation selector (forward/center lock/reverse). The direction-of-rotation selector
located above the trigger switch changes the direction of bit rotation. Setting the trigger switch in the OFF (center
lock) position helps to reduce the possibility of accidental starting when not in use.
Charger port. Insert the jack from the charger adapter to charge the driver. Tool should be charged for 3–5
hours for optimum performance.
Trigger switch. To turn tool on, press the trigger switch. To turn the tool off, release the trigger switch.
LED worklight. For low-light situations.
6
