Maintenance – WEN 3410 Air Filtration System User Manual
Page 10

Maintenance
WARNING: To reduce the risk of injury, unplug the air filter from the power source
before changing the filters or servicing the air filter.
Change the filters (Fig. 5 and 6)
Check the inner and outer filters periodically, depending on the amount of use, and change the
filters when needed. Clogged filters will reduce the amount of air circulating through the filter.
1. Lift up the clips (1) and remove the outer filter (2) from the cabinet housing.
2. Pull the inner filter (3) out of the cabinet.
3. Install a new inner filter.
4. Install a new outer filter. The arrow on the outside of the filter indicates the proper direction
to insert the filter into the cabinet.
Check and replace the fuse (Fig. 7)
1. Turn the fuse cap (1) counterclockwise to loosen and pull the fuse away from the control panel.
2. Insert a new fuse (2amps) (2) in the fuse cap and put it into the control panel.
Air Filtration System Model: 3410
