SPECIFIC SAFETY INSTRUCTIONS
1. Ensure that the directional arrow marked on the blade corresponds with the rotational direction of the motor.
2. With the saw disconnected from the power supply, rotate the blade by hand to ensure it is free from obstruction.
3. Always keep the blade-securing bore and collars clean.
4. Ensure that the blade-securing bolt is securely tightened.
5. Never try to cut freehand. Always ensure that the tile to be cut is pressed firmly against the rip guide.
6. Ensure the material being cut off has sufficient room to move sideways. Failure to do so may result in the off-cut
binding against the blade.
7. Never cut more than one tile at a time.
8. Never cut pieces too small that are not held securely against the rip guide, and provide enough space for the hand to
be a safe distance from the blade.
9. Ensure that the table and surrounding area are clear with the exception of the tile to be cut.
10. Before cutting a tile piece, let the saw blade run freely for a few seconds. If it makes an unfamiliar sound or vibrates
excessively, switch it off immediately and disconnect it from the power supply.
11. Let the blade reach full speed before commencing the cut.
12. Let the blade come to a complete stop before removing any jammed material from around the blade area.
13. Never allow the blade to run dry. Failure to keep the water tray at the recommended level will result in possible over-
heating of the diamond blade.
WARNING!
- 5 -
UNPACKING
Open carton from the top.
Top tray contents:
• Front Extension Tray
• 250 mm Diamond Blade
• Upper Frame Wheels
• Water Pump
• Rip Guide
• Cable Collecting Hanger / Tool Caddy with 2 blade spanners and 6 mm Allen Key
• Bag of miscellaneous hardware (includes drain plug, wheel hardware (2), motor frame mounting screws (3),
hardware for mounting tool caddy (2), motor frame locking knob)
• User's Manual
Middle Tray:
• Stand
Bottom Tray:
• Motor Head Assembly
• Saw Frame with Table
• Rear Water Collection Tray
BT65011 & BT65011IND TILE SAW FEATURES
• Removable rear Collection Water Tray
• Adjustable cutting head allows plunge cuts and for 22.5° and 45° angle cuts
• 250 mm diamond blade cuts tile up to 60 mm thick
• Maximum rip cut length up to 600 mm tile. Diagonal Cut, up to 457 mm tile
• Folded Saw Stand with wheels offers quick set up, as well as easy mobility
ELECTRICAL AND MOTOR SPECIFICATIONS
MODELS BT65011 BT65011IND
Power Supply 230v - 50Hz 110v - 50Hz
Motor 1100w 1100w
Max Depth of Cut 60mm 60mm
Mitre Cutting Angle 22.5° & 45° 22.5° & 45°
Cutting Angle 0° - 45° 0° - 45°
Package Weight 48Kg 48Kg
