SOLUTION TANK ASSEMBLY
ADMIRAL 86038230 03/16/07
5-12
REF
PART NO.
PRV NO.
QTY
DESCRIPTION
SERIAL NO.
FROM
NOTES:
1
86222760
20041
2
CLAMP, 2.0" WORM GEAR
2
86222770
20042
1
CLAMP, 3/8 HOSE (D-SLOT)
3
86003080
27809
1
COVER, VAC MOTOR
4 86003090 27810 1 COVER,
BELT
5 86235500 31081 1
ELBOW, 3/8 MPT X 3/8 TUBE,
PLASTIC
6
86003790
35175
2
GASKET, TANK TO VAC COVER
7 86003920 35231 2
GASKET, VAC COVER (CLP
FAMILY)
8
86281880
39526
1
HOSE,1/2 CLEAR X 12
9
86240090
39527
1
HOSE, 1.5 BLK VAC X 3.0
10
86004340
39528
REF HOSE ASM, 1.5 BLK VAC X 15.5
11
86161450
41348
1
HOUSING, VAC MOTOR
12
86026880
53789
1
VAC MOTOR ASM, CLP FAMILY
12A 86135340
14258
-
BRUSH SET, 120V 5.7 VAC,
AMATEK
* SERVICE
ONLY
12B
86135320
140687
BRUSH SET, 120V VAC, WINDSOR
* SERVICE
ONLY
13
86275690
70525
6
SCR, #10 X 1.0 PPHST TYPE B
14
86032260
75259
1
TANK, ADM SOLUTION
15
86259060
85037
1
VENT, COOLING AIR SMALL
16
86010650
87018
10
WASHER, #10 X 9/16 OD
17
86007970
73864
1
STRAINER, 3/8 IN. NPT 60 MESH
18
86010630
87013
5
WASHER, 1/4 ID X 5/8 OD SS
19
86002730
70085
3
SCR, 1/4-20 X 1/2 PPHMS SS DL
20
86079260
20092
1
CLAMP, 3.5" WORM GEAR
21
86003950
35236
1
GASKET, TANK, L-F
22
86003960
35237
1
GASKET, TANK, L-R
23
86003970
35238
1
GASKET, TANK, RH
24
86068510
40027
1
HOSEBARB, 3/8MPTX1/2 90D DL
25
86210470
70360
2
SCR, 1/4-20 X.75 PPHMS PHIL
26
86010660
87025
2
WASHER, 1/4 LOCK EXT STAR SS
27
86202590
70114
4
SCR, #10 X 3/4 PPHST TYPE B
28
86095840
89183
1
WELDMENT, HANDLE PIVOT ADM8
29
86005810
57245
2
NUT, 1/4-20 HEX NYLOCK SS
30
86181100
02130
1
HOSE ASSY- FILL HOSE
31
8623150
20042
1
CLAMP, 3/8 HOSE (D-SLOT)
32
86197920
40023
1
HOSEBARB, 1/2MPT X 3/8 DL
33
86026670
75277
1
TANK ASM, SOLUTION ADM8
*ITEMS
INCLUDED
