Sheet1, Drawing view1, Fp-lf – Video Mount Products FP-LFB User Manual
Page 2
1
2
17
4
19
18
16
15
14
13
12
11
10
9
8
5
6
7
3
FP-LF
20
22
21
ITEM NO.
DESCRIPTION
QTY.
1
Wall Plate
1
2
Mounting Bracket
2
3
Security Screw M5*P0.8*L20
2
4
Long Allen Key M4
1
5
Screw M4*P0.7*L12
4
6
Screw M5*P0.8*L12
4
7
Screw M6*P1.0*L12
4
8
Screw M8*P1.25*L16.5
4
9
Screw M4*P0.7*L30
4
10
Screw M5*P0.8*L30
4
11
Screw M6*P1.0*L35
4
12
Screw M8*P1.25*L40
4
13
Lock Washer M4
4
14
Lock Washer M5
4
15
Lock Washer M6
4
16
Lock Washer M8
4
17
Washer
5.5*
18*T2.0
8
18
Spacer M6
4
19
Spacer M8
4
20
Magnetic Level
1
21
Lag Screw 5/16"*L2.5"
6
22
Washer
8.3*
19*T1.6
6
