Tennsco Preassembled Lockers Single, Double,and Triple Tier User Manual
Page 2
SINGLE
TIER
DOUBLE
TIER
TRIPLE
TIER
REF.
QUANTITY
QUANTITY
QUANTITY
NO. DESCRIPTION
PART NO. 1 WIDE 3 WIDE
PART NO. 1 WIDE 3 WIDE
PART NO. 1 WIDE 3 WIDE
1
Locker door
LSTD-wwhh
1
3
LDTD-wwhh
2
6
LTTD-wwhh
3
9
2
Coat hook
LCH-1
3
9
LCH-1
6
18
LCH-1
9
27
3
Coat rod *
LCR-ww
1
3
—
—
—
—
—
—
4
Latch
LL-1
3
9
LL-1
4
12
LL-1
6
18
5
Bumper
LB-1
2
6
LB-1
4
12
LB-1
6
18
6
Dart clip
LDC-1
2
6
LDC-1
4
12
LDC-1
6
18
7
Locking channel
LLCA-1
1
3
LLCA-2
2
6
LLCA-3
3
9
8
Lock receiver
LPR-2
1
3
LPR-2
2
6
LPR-2
3
9
9
Reinforcement tab
LRT-1
1
3
LRT-1
2
6
LRT-1
3
9
10
Recessed handle
(painted steel)
LRH-2
1
3
LRH-2
2
6
LRH-2
3
9
or
Recessed handle
(plastic)
LRH-1
1
3
LRH-1
2
6
LRH-1
3
9
or
Recessed handle
(stainless steel)
LRH-3
1
3
LRH-3
2
6
LRH-3
3
9
11
Number plate
LNP-3
1
3
LNP-3
2
6
LNP-3
3
9
12
Logo plate
LNP-2
1
3
LNP-2
2
6
LNP-2
3
9
13
Push plug
LPP-1
2
6
LPP-1
4
12
LPP-1
6
18
∗
Coat rod is only in single entry units 18" and deeper.
Tennsco makes every effort to ensure that all units ship complete with all parts and arrive undamaged.
However, should your unit contain missing or damaged parts, replacements may be obtained directly
from Tennsco. To obtain proper replacement parts, follow the instructions below:
TO OBTAIN PROPER REPLACEMENT PARTS, PLEASE PROVIDE THE FOLLOWING INFORMATION:
•
Model Number
•
Purchase date
•
Description of part(s) needed and part
•
Your company name
number(s) as shown in Parts List (above)
•
Contact person’s name
•
Color
•
Who the product was purchased from
Tennsco Corp., P.O. Box 1888, Dickson, TN 37056-1888
Voice
(800)
251-8184 Fax:
(800)
722-0134
11
13
6
12
10
9
7
8
5
5
4
4
6
4
13
DOOR ASSEMBLY
3
1
2
SINGLE TIER LOCKER
1
2
DOUBLE TIER LOCKER
1
2
TRIPLE TIER LOCKER
IMPORTANT: Locker units are not intended to stand free, and may topple if not
secured. All units must be anchored to the wall, back-to-back, and/or to the floor.
