Star Water Systems Upflow filter User Manual
Installation instructions, Upflow filters

INSTALLATION INSTRUCTIONS
UPFLOW FILTERS
95 North Oak Street • Kendallville, IN 46755
139373
Illustration A
SPECIFICATION CHART A
*Mineral needs replaced approximately every three years with carbon and gravel underbed.
** Mineral needs replenished approximately every year with 136372 Calcite.
Service Position:
Valve 1 - Open
Valve 2 - Closed
Valve 3 - Open
Bypass Position:
Valve 1 - Closed
Valve 2 - Open
Valve 3 - Closed
FW0237
0611
Supersedes
0310
S07UF1016BW
UN10
UN20
Application
Taste, Odor, & Chlorine Removal
(Wide Range of Applications)
Acid Neutralizer
Acid Neutralizer
Mineral Used
Carbon*1 Cu. Ft.
Calcite** 1 Cu. Ft.
Calcite** (2) Cu. Ft.
Gravel Underbed
20 lbs.
20 lbs.
30 lbs.
Flow Rate (Continuous)
5 GPM
5 GPM
7 GPM
Total Space Required
(Inches)
10” x 46”
10” x 46”
12" x 54"
Approx. Ship Weight
With Mineral & Gravel
63 lbs.
133 lbs.
188 lbs.
