This product must be installed in accordance with any state and national codes by
a person familiar with the construction and operation of the product and hazards
involved.

This motion sensor light is designed to be used only with 12 DC Power
[Automotive type], any modifications of the unit may result in a hazard and will
VOID the warranty.

Please do not attempt to open the Motion Sensor back housing as there are no
serviceable parts inside and doing so WILL VOID the warranty.

Please read all of the Smart Light 1000™ installation instructions before
installing the fixture.

IMPORTANT NOTES

Attaching other accessories or devices without the uses of the Revolution 2000

FB™ Fused Relay Box can cause a hazard, may damage the unit, and WILL
VOID the WARRANTY
.

INSTALLING the Smart Light 1000™

IMPORTANT-DISCONNECT THE BATTERY

STEP 1: Remove the old lighting fixture from the RV and clean area of all old sealer,

dirt, etc.

STEP 2: Attach the BLACK or WHITE wire marked positive (+) on the SL-1000 fixture

to the positive wire (+) coming from the RV.

STEP 3: Attach the WHITE wire marked negative (-) on the SL-1000 fixture to the

negative wire (-) coming from the RV.

NOTE: If there are other accessories or devices that together total less than 4 amps that

you would like to trigger using the Smart Light 1000™ you can trigger them by using

the Revolution 2000 FB™ Fused Relay Box. The Revolution 2000 FB™ Fused Relay
Box
is triggered using the YELLOW wire located on the back of the fixture and will
supply voltage to the accessories while protecting the circuitry of the

Smart Light

1000™. The YELLOW wire is shrink wrapped to the Power wire. To access the
YELLOW wire, remove the shrink wrap.

NOTE: Perform functionality test at this step
The Smart Light 1000™ is reverse polarity protected. If it is wired backwards, the unit
will not be damaged. However, if wired incorrectly, the motion sensing functionality will
not work, even though the light can be turned on and off at the switch as with any other
porch light. Thus, it is imperative that you perform this self test in order to assure proper
functionality. To do this test you will have to reconnect the battery.

First, adjust your interior light switch to the on position. Then, turn the light switch off,
then on again. If at this point you find that the light turns on, but the

BLUE LED does not
