1.8 Installation
To setup Avenview C-HDMI-COMPVGA follow these steps for connecting to a device:
1. Power off display source such as DVD Player, Set-top box etc
2. Connect your HDMI and/or DVI source to HDMI input and/or DVI input
3. Connect S/PDIF or Stereo Audio source to RCA Jack or 3.5mm Jack
4. Connect VGA/Component Y cable to C-HDMI-COMPVGA
5. Connect other end of VGA/Component Y cable to VGA or Component input of display
6. Plug in 5V DC power cord to power jack of C-HDMI-COMPVGA
7. Power on C-HDMI-COMPVGA converter
8. Power on HDMI and/or DVI source and display with VGA or Component input.
S/PDIF format is dependent on the embedded digital audio part in the HDMI stream. The S/PDIF
receiver must be able to recognize the input S/PDIF format. C-HDMI-DVIA only separates the
digital audio in HDMI stream and bypasses this decoded audio to the output.
This version does NOT support 8 Channel analog audio applications
S/PDIF audio input can support 2 out of 8 channel audio inputs. S/PDIF audio only supports 48
KHz audio sample rate.
