05_51351_0B Page 6
sTep 7 secURInG YoUR coveR
Pull the cover over the frame. The welded in webbing should be at the front and back of the building. Also note
that the pocket with the cutouts, running along the sides of the cover, should be on the inside and near the
ground. Insert the "S" hook from the ratchets into the hole in the leg of the frame. Next, insert the webbing into
the spindle of the ratchet and tighten ratchet until the webbing overlaps itself, do not tighten all the way yet.
Check to be sure the cover still has an even overhang on the front and rear, adjust as necessary. Once the
cover is even, finish tightening the ratchets, alternating from corner to corner to ensure the cover stays even.
After the cover is tight end to end, remove the cross rails and connectors on oen side of them fram and place
them into the pockets between the cutouts. Atach the crossrail using the 3-way and 4-way cover rail clamps
around the uprights and loosely fasten with the 1/4" x 1-5/8" bolts and 1/4" nuts. Check that the rails are evenly
spaced above the ground on both sides. Push down on the connectors one at a time to tension the cover and
tighten the bolts to hold tightly.
WARnInG:
Do not leave a partially or fully covered unit
without being fully anchored! Serious injury to
persons or property could result.
The ratchets should
be checked monthly
to make sure cover
is tight.
sTep 8
Find the open side of the protective boot and open it. Insert the foot of the
corner leg into the protective boot. When foot is all the way in the boot insert
the top edge of the boot into the hem of the cover. When complete secure the
Velcro on the open side of the boot to close the boot.
