Place cover and secure to canopy frame, Attach remaining bungees – ShelterLogic 23531 10 x 20 Max AP Canopy 2-in-1 Pack - Screen Kit User Manual
Page 6
05-23531-0D
Page 6
Grommet Panels for Bungees
Grommet
Panel
10066
13107
5. PlACE COvER AND SECURE TO CANOPY FRAME
A. Place cover over assembled roof frame with grommet panels facing down, aligned with cross rails.
B. Make sure the cover is properly aligned on the frame, secure the four corners of the cover with bungees
(10066)
to the frame first
.
Attach remaining bungees.
Re-adjust bungees position along cross pole as needed to ensure a tight and even fit of the cover to the frame.
Grommet Panels for Bungees
Grommet Panel
10072
13102
Secure Bungee Around Plastic Ball
Insert Bungee Cord Through Grommet
