ShelterLogic 14553 7 4 x 10 Quick Clamp Canopy User Manual
Page 4
05-14553-0A
Page 4
5. PULL CoVer oVer FrAMe AnD SeCUre:
4. InSerT BoTToM CroSS rAILS:
6. LIFT CoVer ArMS To UPrIGHT PoSITIon
Pull cover over frame. Fasten corners of cover and top rail.
Extend the frame to the fully open position. Insert the side poles into pockets created by the hook and loop
fasteners on each side. Push tightly together along cover edge so cover is very tight.
Corner Hook & Loop Fasteners
Cover Edge Hook & Loop Fasteners
802787
802786
802787
