5-bay raid station 6
1. Power LED
DESCRIPTION GREEN LED
Power On On
Power Off Off
2. PC Link LED
DESCRIPTION GREEN LED
PC Link Unplugged / No Power Off
PC Link Plugged (Idle) On
PC Link Plugged (Active) On
3. Front panel LEDs
DESCRIPTION GREEN LED RED LED
HDD Unplugged / No Power Off Off
HDD Plugged (Idle) On Off
HDD Plugged (Active) Blink (On) Off
Error State (one or more bad partial volumes) Off On
HDD Rebuild (a physical partition is being
rebuild; e.g. Mirroring Mode) Off Blink (On)
4. HDD tray LEDs
DESCRIPTION GREEN (UPPER) GREEN (LOWER)
HDD Unplugged / No Power Off Off
HDD Plugged (Idle) On Off
HDD Plugged (Active) Blink (On) Off
Error State (one or more bad partial volumes) Off On
HDD Rebuild (a physical partition is being
rebuild; e.g. Mirroring Mode) On Blink (On)

