SHARKOON X-Tatic Digital - Manual (Page 9)

X-TATIC DIGITAL
2. Turn the microphone until the indications on the microphone and on the headset are
opposite to each other (fig. 3).
3. Press the microphone’s plug into the headset’s jack completely and turn the micro-
phone to the front and into the desired position.
6. The SCU at a glance
A – Analogue audio outputs (3x 3.5 mm jack for front, surround and center speaker)
B – LEDs for:
a – Power on / off
b – Dolby Digital on / off
c – Dolby ProLogic on / off
d – DRC on / off
C – Analogue audio outputs for the X-Tatic headset (2x 9-pin analogue plug)
fig. 3
A
B
C
a
b
c
d
A
C
