X-TATIC ANALOG

19

6. Connecting the microphone to the headset

1. Insert the microphone’s 3.5 mm stereo plug (fig. 1) loosely into the headset’s micro-

phone connector (fig. 2).

B – Cable adapter

a – 9-pin analog jack

b – 3.5 mm stereo plug for each

channel:

1 – Microphone connector

(pink)

2 – Subwoofer connector

(orange)

3 – Connector for rear speakers

(black)

4 – Connector for front

speakers (green)

5.2 The connectors

A – Headset connectors

a – 9-pin analog connector

b – ISO power connector

fig. 1

fig. 2

A

B

a

b

1

2 3 4

a

b
