5.1 The volume controller
A – Volume adjustment for each channel after pressing the according button (button
illuminated) or main volume adjustment respectively (all buttons illuminated) as
well as volume on/off (by pressing this controller)
B – Microphone volume (only Xbox 360)
C – Control button for the front, rear and center speaker as well as for the subwoofer
(Sub). The volume level is displayed by different colors.
D – Microphone on/off
(E – Connection for Xbox 360 microphone – see below 8.)
