WPM V2 SERIE
5. installation
Remove the previously installed PSU from the case. Proceed as follows:
1. Switch off your PC. Disconnect the PSU’s power cord from the wall outlet and your
PSU. Unplug all cables connected to the PC case (e.g. keyboard, mouse, etc.)
2. Open the PC case (for additional information refer to the PC case’s manual)
3. Disconnect all cable connections between the PSU and other PC components
(e.g. mainboard, HDDs, drives, fans, etc.).
4. Remove the mounting screws connecting the PSU to the PC case and carefully
remove the PSU from the case.
5.1 installing the PSU into the PC case
1. Insert the PSU into the PC case and place it against the PSU bracket on the
case’s back side.
2. Screw the PSU to the case from the outside using the included screws. Be careful
not to cover the fan/air intake of the built-in PSU.
Note:
All connectors are designed fault-preventing to avoid misconnection. If you are unable to the male
connector-to-female connector of the drive or peripheral, please check if both connectors are attached in
the correct orientation.
Do not force to plug the connectors within the incorrect orientation, nor modify any of the components,
as this will damage the PSU and other hardware. SHARKOON warranty does not cover damage cause
by incorrect handling.
5.2 Connecting mainboard and graphics card(s)
1. Plug the ATX power connector (fig. 1) to the respective jack on the mainboard. .
fig. 1

