WPM BRONZE SERIE 12

5.4 Connecting the cables to the PSU
Connect the modular cables to the PSU according to the connector coding (see above fig. 4).
5.5 Checking all connections
Make sure that all devices are connected properly then plug the PSU’s power cord to a wall outlet and
switch the power supply on. This ends the installation of the PSU.
6. Troubleshooting
If the PSU does not work properly, check the following:
1. Is the power cord correctly connected to a wall outlet and the PSU’s power connector?
2. Ensure that the on/off switch is in the “I” position.
3. Check if the main power connector is correctly plugged to the mainboard.
4. Check if the power connectors are properly connected to the peripheral devices in case the short
circuit protection function was activated when switching on the PSU.
5. Turn the power switch “off” and back “on” several times, with a minimum cycle pause of 5 seconds.
6. If the PSU still does not start, please contact [email protected]
On/Off switch of the power supply
