Seed Hawk
®
Manual Calibration Guide
2
Meter Calibration & Procedures
NOTE: For convenient
calibration, use the remote
calibration console that
attaches to the tank
harness.
Meter calibration is a procedure that allows for accurately setting
the individual meters to apply the desired rate of material. Before
a meter calibration can be done the implement width must be
entered and the speed calibration must be completed (See
Section Setup Wizard and Calculating the speed Calibration
sections of your Seed Hawk Viper Pro™ Manual).
Note: Wing down pressure circuit must be active to operate
hydraulic drive motors and meter gates.
Attention: Exit to the Seed Hawk Viper Pro Main Menu on
the Viper monitor before powering up the Remote
Calibration Console.
Ensure meter gates are fully open for proper product flow.
Note: All Meters on a machine must be individually
calibrated. Calibrations must be done each time a crop is
changed.
