Page 112: Wireless group (menu)

112 •
Channels
Within each wireless group, the devices communicate
with each other on three channels (C1, C2, C3).
When you set up a wireless group with this device, it
suggests three channels guaranteeing optimum data
transmission. We recommend accepting the channel
numbers suggested.
You can also select the channel numbers (0 - 99)
manually - for example if you want to set up more than
one wireless group.
The channels must be sufficiently far apart to ensure
trouble-free data transmission. We recommend a
spacing of at least 30. Each channel number may only
be used for one channel.
Example of configuration; channel numbers when
setting up 3 wireless groups within one surgery:
• wireless group 0: C1=_0, C2= 30, C3=60
• wireless group 1: C1=10, C2=40, C3=70
• wireless group 2: C1=20, C2=50, C3=60
Detection of devices
If you wish to set up a wireless group with this device, it
searches for other active devices from the
seca 360° wireless
system. The devices detected are
shown by numbers in the form of modules in the device
display (e.g. MO 3). The meaning of the numbers is as
follows:
• 1: personal scales
• 2: height-measuring rod
• 3: wireless printer
• 4: PC with seca USB wireless module
• 7: baby scales
• 5, 6 and 8-12: reserved for system expansion
8.2
Operate measuring station in a
wireless group (menu)
The head slide and multifunctional display of the
measuring station are made to form a wireless group at
the factory. Further devices can be integrated in the
wireless group using both components as a starting
point. The multifunctional display is more convenient for
this process.
0
C1
C3
C2
