SANDPIPER EB1-SM - Manual (Page 6)

Model EB1-SM Type 3 Page 6 520-079-000 9/00
REPAIR PARTS LIST and DRAWING
Type 3
1 095-051-551 Body, Spool Valve 1
2 031-039-000 Sleeve & Spool Set 1
3 560-058-360 O-Ring 8
4 165-038-356 Cap, End 2
5 675-043-115 Ring, Retainer 2
6 165-042-157 Cap, Valve Body 1
7 360-056-360 Gasket 1
8 360-057-360 Gasket 1
9 360-058-360 Gasket 1
10 095-074-000 Pilot Valve Body Assembly 2 1
10-A 095-071-551 Pilot Valve Body 1
10-B 755-025-000 Sleeve (w/O-Ring) 1
10-C 560-033-360 O-Ring (Sleeve) 4
10-D 775-014-000 Spool (w/O-Ring) 1
10-E 560-023-360 O-Ring (Spool) 4
10-F 675-037-080 Retaining Ring 1
11 170-063-330 Capscrew, Hex Head 1
12 901-035-330 Washer, Flat 1 15
13 542-001-330 Nut, Square 1
14 170-033-330 Capscrew, Hex Head 4
15 901-005-330 Washer, Flat 4
16 170-043-330 Capscrew, Hex Head 1 17
17 114-007-157 Bracket, Intermediate 1
18 196-042-157 Chamber, Diaphragm 1
19 196-043-157 Chamber, Diaphragm 1
20 560-040-360 O-Ring 2
21 560-001-360 O-Ring 2
22 135-013-162 Bushing 2
23 675-042-115 Ring, Retainer 2
24 620-007-114 Plunger, Actuator 2
25 132-022-360 Bumper 2
26 070-012-170 Bearing, Sleeve 2
27 720-010-375 Seal, U-Cup 2
28 545-004-330 Nut, Hex 8
29 901-012-180 Washer, Sealing 2
30 196-073-157 Chamber, Outer 2
31 675-040-360 Ring, Sealing 2
32 685-039-120 Rod, Diaphragm 1
33 132-019-360 Bumper 2
34 612-108-157 Plate, Outer Diaphragm (incl. item 53) 2
35 612-022-330 Plate, Inner Diaphragm 2
36 286-008-356 Diaphragm 2
286-008-360 Diaphragm 2
286-008-363 Diaphragm 2
286-008-364 Diaphragm 2
286-008-365 Diaphragm 2
286-008-354 Diaphragm 2
37 170-045-330 Capscrew, Hex Head 8
38 171-037-330 Capscrew, Hex Head (Spec.) 3 4
39 670-035-157 Ball Retainer/Cap 4
40 560-083-360 O-Ring 4
ITEM TOTAL
NO. PART NUMBER DESCRIPTION RQD.
Repair Parts shown in bold face (darker) type
are more likely to need replacement after
extended periods of normal use. The pump owner
may prefer to maintain a limited inventory of these
parts in his own stock to reduce repair downtime
to a minimum.
IMPORTANT: When ordering repair parts
always furnish pump model number, serial
number and type number.
MATERIAL CODES
The Last 3 Digits of Part Number
000...Assembly, sub-assembly;
and some purchased items
010...Cast Iron
015...Ductile Iron
025…Music Wire
080...Carbon Steel, AISI B-1112
100...Alloy 20
110...Alloy Type 316 Stainless Steel
112...Alloy “C”
114...303 Stainless Steel
115...301/302/304 Stainless Steel
120...416 Stainless Steel (Wrought Martensitic)
148...Hardcoat Anodized Aluminum
150...6061-T6 Aluminum
151...6063-T6 Aluminum
154...Almag 35 Aluminum
155 or 156...356-T6 Aluminum
157...Die Cast Aluminum Alloy #380
159...Anodized Aluminum
162...Brass, Yellow, Screw Machine Stock
170...Bronze, Bearing Type, Oil Impregnated
180...Copper Alloy
330...Plated Steel
331...Chrome Plated Steel
332...Electroless Nickel Plated
335...Galvanized Steel
356...Injection Molded Hytrel
357...Rupplon (Urethane Rubber)
358…E.P.D.M. (Food Grade)
359…Polyurethane
360...Buna-N Rubber. Color coded: RED
363...Viton (Fluorel). Color coded: YELLOW
364...E.P.D.M. Rubber. Color coded: BLUE
365...Neoprene Rubber. Color coded: GREEN
366...Food Grade Nitrile. Color coded: WHITE
375...Fluorinated Nitrile
405...Cellulose Fibre
408...Cork and Neoprene
425...Compressed Fibre
440...Vegetable Fibre
500...Delrin 500
501...Delrin 570
520...Injection Molded PVDF, Natural
Color, Food Grade/USDA Acceptable
541...Nylon, Glass Filled
550...Polyethylene
551...Polypropylene
552…Unfilled Polypropylene
555…PVC
570…Rulon II
580...Ryton
590…Valox
600...Teflon (virgin material) Tetrafluoroethylene (TFE)
603...Blue Gylon
604...Teflon, Diaphragm
610…Teflon Encapsulated Silicon
611...Teflon Encapsulated Viton
632…Neoprene Rupplon
633…Viton/Teflon
634…E.P.D.M./Teflon
636…White Nitrile/Teflon
Delrin, Teflon, Viton and Hytrel are registered
tradenames of E.I. DuPont.
Gylon is a registered tradename of Garlock, Inc.
Nylatron is a registered tradename of
PolymerCorporation.
Rulon II is a registered tradename of
Dixion Industries Corp.
Ryton is a registered tradename of
Phillips Chemical Company.
Valox is a registered tradename of
General Electric Company.
Santoprene is a registered tradename of Monsanto Corp.
®SandPIPER and Rupplon, and Warren Rupp are
registered tradenames of Warren Rupp, Inc.
Model EB1-SM
