Page 5
520-035-000 2/02
Model EB2-M, EB2-MB, MEB2-M, EB50M Type 3 Page 5
ITEM
TOTAL
NO.
PART NUMBER
DESCRIPTION
RQD.
1
070-006-170
Bearing, Sleeve
2
2
114-002-156
Bracket, Intermediate
1
114-002-010
Bracket, Intermediate
1
3
720-004-360
Seal, U-Cup
2
4
135-008-000
Bushing, Threaded, with o-ring
2
135-016-162
Bushing, Threaded, with o-ring
2
(MEB2-M only)
5
620-004-114
Plunger, Actuator
2
620-011-114
Plunger, Actuator (MEB2-M only)
6
095-073-000
Assembly, Pilot Valve*
1
6-A
095-070-551
Valve Body
1
6-B
755-025-000
Sleeve (with o-rings)
1
6-C
560-033-360
O-Ring (Sleeve)
4
6-D
775-026-000
Spool (with o-rings)
1
6-E
560-023-360
O-Ring (Spool)
2
6-F
675-037-080
Retaining Ring
1
7
360-041-425
Gasket, Valve Body
1
8
560-001-360
O-Ring
2
9
095-043-156
Body, Valve
1
095-043-010
Body, Valve
1
10
132-014-358
Bumper, Valve Spool
2
11
165-011-157
Cap, End
2
165-011-010
Cap, End
2
12
360-048-425
Gasket, Valve Body
1
13
360-010-425
Gasket, End Cap
2
14
560-020-360
O-Ring
6
15
031-012-000
Sleeve & Spool Set
1
16
170-032-330
Capscrew, Hex Head
8
170-032-115
Capscrew, Hex Head
8
17
170-045-330
Capscrew, Hex Head
4
170-045-115
Capscrew, Hex Head
4
18
132-002-360
Bumper, Diaphragm
2
19
196-001-157
Chamber, Inner
2
196-001-010
Chamber, Inner
2
20
286-007-365
Diaphragm
2
286-007-363
Diaphragm
2
286-007-360
Diaphragm
2
286-007-366
Diaphragm
2
286-007-364
Diaphragm
2
286-007-356
Diaphragm
2
21
560-022-360
O-Ring
2
22
685-007-120
Rod, Diaphragm
1
23
170-023-330
Capscrew, Hex Head
16
170-023-115
Capscrew, Hex Head
16
24
170-024-330
Capscrew, Hex Head
8
170-024-115
Capscrew, Hex Head
8
25
618-003-330
Plug, Pipe (SS & Alloy C Qty.2)
4
618-003-110
Plug, Pipe (SS Only) (AX Qty. 4)
2
618-003-112
Plug, Pipe (Alloy C Only)
2
26
900-006-330
Washer, Lock
8
900-006-115
Washer, Lock
8
27
612-047-330
Plate, Diaphragm
2
28
612-039-157
Plate, Outer
2
612-097-110
Plate, Outer
2
612-039-010
Plate, Outer
2
29
807-026-330
Stud
2
Repair Parts shown in bold face (darker)
type are more likely to need replacement
after extended periods of normal use. They
are readily available from most Warren
Rupp distributors. The pump owner may
prefer to maintain a limited inventory of
these parts in his own stock to reduce re-
pair downtime to a minimum.
IMPORTANT: When ordering repair parts
always furnish pump model number, serial
number and type number.
MATERIAL CODES
The Last 3 Digits of Part Number
000…Assembly, sub-assembly;
and some purchased Items
010…Cast Iron
012…Powered Metal
015…Ductile Iron
020…Ferritic Malleable Iron
025…Music Wire
080…CarbonSteel AISI B-1112
100…Alloy 20
110…Alloy Type 316 Stainless Steel
111…Alloy Type 316 Stainless Steel (Electro Polished)
112…Alloy “C”
113…Alloy Type 316 Stainless Steel (Hand Polished)
114…303 Stainless Steel
115…302/304 Stainless Steel
117…440-C Stainless Steel (Martensitic)
120…416 Stainless Steel (Wrought Martensitic)
123…410 Stainless Steel (Wrought Martensitic)
148…Hardcoat Anodized Aluminum
149…2024-T4 Aluminum
150…6061-T6 Aluminum
151…6063-T6 Aluminum
152…2024-T4 Aluminum (2023-T351)
154…Almag 35 Aluminum
155 or 156…356-T6 Aluminum
157…Die Cast Aluminum Alloy #380
158…Aluminum Alloy SR-319
159…Anodized Aluminum
162…Brass, Yellow, Screw Machine Stock
165…Cast Bronze, 85-5-5-5
166…Bronze SAE 660
170…Bronze, Bearing Type, Oil Impregnated
180…Copper Alloy
310…Kynar Coated
330…Zinc Plated Steel
331…Chrome Plated Steel
332…Electroless Nickel Plated
335…Galvanized Steel
336…Zinc Plated Yellow Brass
337…Silver Plated Steel
340…Nickel Plated
342…Filled Nylon
354…Injection Molded #203-40 Santoprene
- Duro 40D ± 5; Color: RED
355…Thermoplastic Elastomer
356…Hytrel
357…Rupplon (Urethane Rubber) Color
coded:PURPLE
358…Rupplon (Urethane Rubber)
Color coded:PURPLE
(Some Applications, Compression Mold)
359…Urethane Rubber
360…Buna-N Rubber Color coded: RED
361…Buna-N
363…Viton (Fluorel) Color coded: YELLOW
364…E.P.D.M. Rubber Color coded: BLUE
365…Neoprene Rubber Color coded: GREEN
370…Butyl Rubber Color coded: BROWN
371…Philthane (Tuftane)
List continued next page
*Available in Kit Form. Order P/N 031-055-000 which also includes
items 5, 7, 12 & 47.
REPAIR PARTS LIST and DRAWING
Type 3
EB2-M
EB2-MB
MEB2-M EB50M
®
