ITEM TOTAL
NO. PART NUMBER DESCRIPTION RQD.
1 070-006-170 Bearing, Sleeve 2
2 114-002-156 Bracket, Intermediate 1
114-002-010 Bracket, Intermediate 1
3 720-004-360 Seal, U-Cup 2
4 135-008-000 Bushing, Threaded,
w/O-Ring 2
5 620-004-114 Plunger, Actuator 2
6 095-073-000 Pilot Valve Body Assy.* 1
6-A 095-070-551 Pilot Valve Body 1
6-B 755-025-000 Sleeve (w/O-Ring) 1
6-C 560-033-360 O-Ring (Sleeve) 4
6-D 775-026-000 Spool (w/O-Ring) 1
6-E 560-023-360 O-Ring (Spool) 2
6-F 675-037-080 Retaining Ring 1
7 360-041-425 Gasket, Valve Body 1
8 560-001-360 O-Ring 2
9 095-043-156 Body, Valve 1
095-043-010 Body, Valve 1
10 132-014-358 Bumper, Valve Spool 2
11 165-011-157 Cap, End 2
165-011-010 Cap, End 2
12 360-048-425 Gasket, Valve Body 1
13 360-010-425 Gasket, End Cap 2
14 560-020-360 O-Ring 6
15 031-018-000 Sleeve & Spool Set 1
16 170-032-330 Capscrew, Hex Head 8
17 170-045-330 Capscrew, Hex Head 4
18 132-002-360 Bumper, Diaphragm 2
19 196-001-157 Chamber, Inner 2
196-001-010 Chamber, Inner 2
20 286-007-365 Diaphragm 2
286-007-363 Diaphragm 2
286-007-360 Diaphragm 2
286-007-356 Diaphragm 2
286-007-364 Diaphragm 2
21 560-022-360 O-Ring 2
22 685-007-120 Rod, Diaphragm 1
23 170-024-330 Capscrew, Hex Head 8
24 618-003-330 Plug, Pipe (SS Qty. 2) 4
618-003-110 Plug, Pipe 2
25 900-006-330 Washer, Lock 8
26 612-047-330 Plate, Diaphragm 2
27 902-003-000 Stat-O-Seal 2
28 530-008-000 Muffler, Exhaust 1
31 031-021-156 Main Air Valve Assembly
(Inc. Items 9, 10, 11, 13,
14, 15, 16)
1
031-021-010 Main Air Valve Assy. 1
REPAIR PARTS LIST and DRAWING
Model EB3-SM
Type 3
WARREN RUPP, INC. A Unit of IDEX Corporation • P.O. Box 1568 • Mansfield, Ohio 44901-1568 USA • (419) 524-8388 • Fax (419) 522-7867 • www.warrenrupp.com
520-057-000 8/00 Model EB3-SM Page 6
Repair Parts shown in bold face (darker)
type are more likely to need replacement
after extended periods of normal use.
They are readily available from most
Warren Rupp distributors. The pump
owner may prefer to maintain a limited
inventory of these parts in his own stock to
reduce repair downtime to a minimum.
IMPORTANT: When ordering repair parts
always furnish pump model number, serial
number and type number.
MATERIAL CODES
The Last 3 Digits of Part Number
000... Assembly, sub-assembly; and some
purchased items
010... Cast Iron
015... Ductile Iron
025... Music Wire
080... Carbon Steel, AISI B-1112
100... Alloy 20
110... Alloy Type 316 Stainless Steel
112... Alloy “C”
113... Hand Polished 316 Stainless Steel
114... 303 Stainless Steel
115... 301/302/304 Stainless Steel
120... 416 Stainless Steel (Wrought Martensitic)
148... Hardcoat Anodized Aluminum
150... 6061-T6 Aluminum
151... 6063-T6 Aluminum
154... Almag 35 Aluminum
155 or 156...356-T6 Aluminum
157... Die Cast Aluminum Alloy #380
159... Anodized Aluminum
162... Brass, Yellow, Screw Machine Stock
170... Bronze, Bearing Type, Oil Impregnated
180... Copper Alloy
330... Plated Steel
331... Chrome Plated Steel
332... Electroless Nickel Plated
335... Galvanized Steel
354... Injection Molded #203-40 Santoprene —
Duro 40D +/-5; Color: RED
356... Injection Molded Hytrel
357... Rupplon (Urethane Rubber)
358... E.P.D.M. (Food Grade)
359... Polyurethane
360... Buna-N Rubber. Color coded: RED
363... Viton (Fluorel). Color coded: YELLOW
364... E.P.D.M. Rubber. Color coded: BLUE
365... Neoprene Rubber. Color coded: GREEN
366... Food Grade Nitrile. Color coded: WHITE
375... Fluorinated Nitrile
405... Cellulose Fibre
408... Cork and Neoprene
425... Compressed Fibre
440... Vegetable Fibre
500... Delrin 500
501... Delrin 570
520... Injection Molded PVDF, Natural Color,
Food Grade/USDA Acceptable
541... Nylon, Glass Filled
550... Polyethylene
551... Polypropylene
552... Unfilled Polypropylene
555... PVC
570... Rulon II
580... Ryton
590... Valox
600... Teflon (virgin material) Tetrafluoroethylene (TFE)
603... Blue Gylon
604... Teflon — Diaphragm
610... Encapsulated Silicon
611... Teflon Encapsulated Viton
632... Neoprene Rupplon
633... Viton/Teflon
634... E.P.D.M./Teflon
636... White Nitrile/Teflon
Delrin, Teflon, Viton and Hytrel are registered
tradenames of E.I. DuPont.
Gylon is a registered tradename of Garlock, Inc.
Nylatron is a registered tradename of Polymer
Corporation.
Rulon II is a registered tradename of Dixion Industries Corp.
Ryton is a registered tradename of Phillips Chemical
Company.
Valox is a registered tradename of General Electric Company.
Warren Rupp, SandPIPER, Tranquilizer, and Rupplon are
registered tradenames of Warren Rupp, Inc.
