Typical code = 25. z f. b b. e e e - l f – SANDPIPER X25 User Manual
Page 4
HG-CF-921 Rev. L - 28.07.05
Page 4
FLUID CONNECTIONS
CAPACITY
MAX SOLIDS
MAX DISCHARGE HEAD
DISPLACEMENT/STROKE
1” RJT Male
0 - 136 Litres/Minute
(0 - 30 Gallons/Minute)
5 MM
(3/16”)
88 Meters
(289 ft)
0.5 Litres
(0.11 UK Gallons)
MAX. WORKING PRESSURE
AIR INLET
TEMPERATURE LIMITS
PUMP WEIGHTS :-
8.6 Bar (125 psi)
3/8” BSP (F)
Determined by Elastomers
21.5 Kg
TECHNICAL DATA
TYPICAL CODE =
25. Z F. B B. E E E - L F
WETTED COMPONENTS
Z : 316L STAINLESS STEEL
(POLISHED)
NON - WETTED COMPONENTS
F : NICKEL PLATED ALUMINIUM
S: 316L STAINLESS STEEL
VALVE TYPE
B : BALL
SUCTION ORIENTATION
B : BOTTOM
VALVE SEATS
E : EPDM (FOOD GRADE)
S : STAINLESS STEEL
VALVE BALLS
E : FOOD GRADE EPDM
T : PTFE
S : 316 STAINLESS STEEL
DIAPHRAGMS
E : EPDM (FOOD GRADE)
O : ONE PIECE PTFE
MODEL
25 : STANDARD
X25 : ATEX CAT. 2
Operating Temperatures
Materials
Maximum
Minimum
Optimum
EPDM -
Shows very good water and chemical resistance. Has poor resistance to oils and solvents, but is fair on
ketones and alcohols.
212
o
F
100
o
C
-11
o
F
-24
o
C
50
o
to 212
o
F
10
o
to 100
o
C
Virgin PTFE -
Chemically inert, virtually impervious. Very few chemicals are known to react chemically with
PTFE : molten alkali metals, turbulent liquid or gaseous fluorine and a few fluoro-chemicals such as chlorine
trifluoride or oxygen difluoride which readily liberate free fluorine at elevated temperatures.
356
o
F
180
o
C
32
o
F
0
o
C
50
o
to 212
o
F
10
o
to 100
o
C
•
Gentle pumping action to avoid damage to food and
beverage products.
•
Range of RJT/DIN/FERRULE connections.
•
Self priming for emptying containers.
•
Food grade elastomers – EPDM/PTFE
•
Pressures to 8.6 bar.
•
Capable of handling high viscosity & SG fluids.
•
Certified CIP cleanable.
•
EU Design approval
•
316L Stainless Steel
